295W Beam Moving Head Light

KL-MB295

295W Beam Moving Head Light

Product Overview

This high-performance moving head spot light is designed for stage lighting, concerts, theaters, and live events. Featuring precise optical components, advanced color and gobo systems, full pan/tilt movement, and intelligent cooling, it delivers versatile lighting effects for professional productions.

Application Areas

Concert Stages
Theater Productions
TV and Film Sets
Clubs and Entertainment Venues
Live Event Lighting

Product Advantages

✔ Advanced Optical System for Crisp, Clear Beam Effects
✔ Full Pan/Tilt Motion with Precision Magnetic Encoder
✔ Versatile Color & Gobo Effects, Including Half-Color and Rainbow
✔ Intelligent Thermal Management for Long Operation Life
✔ DMX512 & Multi-Mode Control for Professional Shows
✔ Lightweight and Compact Design for Easy Installation

Technical Specification

Product Overview

High-performance 295W LED moving head spot light
Designed for professional stage lighting: concerts, theaters, TV productions, live events
Precision optical system with rich color and gobo effects
Dual prism system and advanced motion control technology for dynamic lighting

Electrical Specifications

Voltage: AC 110V–240V, 50/60Hz
Total Power: 450W

Light Source Specifications

Light Source: 295W high-brightness bulb

Optical System

High-precision multi-element optical lens system
Beam Angle: 0° to 8° narrow beam for sharp aerial effects

Dimming / Strobing

Dimming: 0 to 100% smooth linear adjustment
Strobing: Mechanical strobe with variable-speed effect and strobe macro functions
Strobe Frequency: 0.5 to 14 times per second

Color System

Fixed Colors: 14 color filters plus white light, supports half-color effect
Color Filter Wheel: 1 six-color rainbow effect filter

Gobo System

Gobo Wheel: 13 fixed gobos plus open (white light)
Effect: Soft gobo diffusion for dreamy and atmospheric projection effects

Prisms

Prism System: 8-facet prism, 8+8+8 multi-prism configuration
Feature: Dual prisms can be overlapped and rotated independently in both directions

Focus / Zoom

Beam Angle: 0° to 8° ultra-narrow beam with precise focusing

Movement Control

Pan Movement: 540°
Tilt Movement: 270°
Motor System: Three-phase stepper motors with magnetic encoder positioning technology for high precision and smooth movement

Control System

Control Modes: DMX512, Master/Slave, Auto Run, Sound Control
Channel Mode: 16CH
Display: Touchscreen interface with fan speed monitoring, lamp operating time display, and remote power control

Data / Power Transmission
