Electrical Specifications

• Voltage: AC110V–240V, 50/60Hz
• Power Consumption: 300W

Light Source

• Light Source: 251W Bulb
• Color Temperature: 6700K / 4500K / 3200K
• Lifespan: 20,000 hours

Optical System

• Illuminance: 500,000 lux @ 20 meters
• Beam Angle: 3.8°–45°
• Optical Lens: High-precision optical lens group system
• Focus: Linear electronic focus

Color System

• 14 colors + white
• Half-color effect
• Bidirectional rainbow effect
• 7-color effect wheel

Gobo System

• Static Gobo Wheel: 14 fixed gobos + white
• Bidirectional gobo flow effect
• Gobo shake effect
• Dynamic Effects: 3 glass dynamic gobos

Prism System

• Dual rotating prisms
• 8-facet prism + 16-facet prism
• Prism stacking effect
• Independent bidirectional rotation

Dimming & Strobe

• 0–100% linear dimming
• Mechanical strobe + variable-speed strobe
• Strobe frequency: 0.5–14 times/second
• Built-in strobe macros

Frost Effect

• Adjustable frost filter for soft beam effects

Movement Control

• Pan: 540°
• Tilt: 270°
• Pan Speed: 2.6s / 540°
• Tilt Speed: 1.24s / 270°
• Three-phase stepper motor with magnetic encoder positioning

Control System

• DMX512
• Master/Slave Mode
• Auto Run Mode
• Sound Control Mode
• Channel Modes: 16CH / 20CH
• Touchscreen display interface
• Remote lamp on/off control
• Fan speed and lamp usage monitoring

Cooling System

• Intelligent temperature monitoring
• Automatic fan speed adjustment
• Efficient airflow-guided heat dissipation

Protection & Housing

• IP Rating: IP20
• Housing: High-temperature resistant plastic + high-strength alloy cold-pressed core structure

Physical Specifications

• Dimensions: 310 × 210 × 530 mm
• Net Weight: 13.8 kg
