Product Features

• 1024 DMX Channels
• Controls Up to 96 Fixtures
• 40 Primary + 40 Fine Channels per Fixture
• Avolite Pearl R20 Library Supported
• Fixture Re-patch Function Supported
• Pan/Tilt Swap Function Supported
• Reversed Channel Output Supported
• Channel Slope Modification Supported
• 60 Programmable Scenes
• 10 Scenes Simultaneously Running
• 600 Total Scene Steps
• Advanced Shape Generator System
• Real-Time Blackout Function
• USB Memory Support (FAT32)
• Multi-Mode Master Control System

Technical Specifications

DMX Control System

• DMX Channels: 1024
• Fixture Capacity: 96 Fixtures
• Channels per Fixture:
  • 40 Primary Channels
  • 40 Fine-Tuning Channels

Fixture Library

• Supported Library: Avolite Pearl R20
• Re-patch Fixture Address: Supported

Scene Programming

• Total Scenes: 60
• Simultaneous Scene Playback: 10 Scenes
• Total Scene Steps: 600 Steps
• Scene Timing Control:
  • Fade In / Fade Out
  • LTP Slope Control

Shape Generator System

• Built-in Shape Generator for:
  • Dimmer
  • Pan/Tilt
  • RGB
  • CMY
  • Color
  • Gobo
  • Iris
  • Focus

Shape Features

• Each Scene Supports Up to 5 Shapes
• Up to 10 Shapes Running Simultaneously

Control Functions

• Master Slider Modes:
  • Global Control
  • Playback Control
  • Fixture Control
• Channel Value Control via Wheel
• Channel Value Control via Slider
• Dimmer Control via Slider
• Scene Swop Function
• Flash Scene Function
• Real-Time Blackout Function

Channel Processing

• Pan/Tilt Swop Supported
• Channel Output Reversal Supported
• Channel Slope Modification Supported

Storage System

• USB Memory Support
• File System: FAT32 Compatible
