Light Source
Light source: 295W
Life expectancy: 1,500 hours
Optical System
Ballast: Electronic Ballast
Lens: Anti-reflective coated glass lens
Focus: Linear Motorized focus
Dimmer: 0-100% linear dimming
Beam Angle: 2 degree
High light output 142000LUX@ 20M
Control Program
Prism: 8-facet prism and 32 facets Prism, bidirectional
rotatable at variable speeds
Frost effect+Rainbow effect
Strobe: 0-20 times/second
Motor: 3-phase motor
A fan with a speed control board can effectively
reduce noise, protect the light
PAN & TILT
Pan movement: 540°
Tilt movement: 270°
Automatic Pan/Tilt position correction
Gobos Wheel
1 Rotation Gobo Wheel: 17 gobos + white, wheel
rotation and shake
Color Wheel
Color Wheel: 13 colors +white, color fine-tuning,
rotation with variable direction and speed, with a
rainbow effect
Electrical & Connectors
Power supply with electronic auto-ranging
Voltage: AC90-250V 50/60Hz
Power: 500W
PowerCon IN/OUT
3-pin & 5-pin XLR connectors IN/OUT
Cooling System: No noise fan
Lighting Specification
Height: 590 mm
Width: 480 mm
Depth: 410 mm
Weight: 18kg
Gross Weight:20KG
IP Grade: IP20
