Light Source
Light source specification: 371W/350W
Life expectancy :1,500h
Optical System
Color temperature: 3200K-8000K linear adjustment
Lens: high-precision optical lens
Power Supply
Input voltage: AC115/230V 50/60Hz
Input power: 550W/500W
Ballast: 350W multi-energy electronic ballast
Functional Effect
Soft mirror: 8°–60° independent soft light
Beam Angle:: 0-1.5°
Focus angle: 1.5°–20° linearly adjustable
Dimming: Dual dimming version dimming, super
smooth and flicker-free dimming
High-speed strobe: double-chip strobe, synchronous
and asynchronous strobe. The strobe speed is 0.3-20
times per second adjustable speed
Color wheel: 13 colors + white light
Fixed pattern: 14 patterns + white light, two-way
shaking, animation, running water
Dynamic pattern: 9 patterns + white light + water ripple,
with variable speed shaking effect, two-way variable
speed
Flow effect: the self-rotating gobo can be changed.
Aperture function: with a macro command
Prism: 8+6 (angle 10–20° can be scaled freely
Focusing: Using a high-precision glass optical lens,
linear electric focusing and zooming in
Controls Program
Control mode: DMX/DRM/DMX antenna (optional)
Channel mode: 19 channels in simplified mode, 24
channels in standard mode
Display system: 2.5-inch touch LCD display, Chinese
and English display, 180-degree rotation
Pan&Tilt Axis
Pan rotation angle: 540° (2.9 seconds)
Tilt rotation angle: 270° (1.5 seconds)
Pan&Tilt axis position correction
Lighting Specifications
Height: 635 mm
Width: 420mm
Depth: 295mm
Net weight: 20KG
Protection class: IP 20
Working environment: 0-45℃
