light Source
Light source: 230WBulb
Optical System
Optical equipment: 3-lens combination coating lens
group,
zoom: 0-5°
Power Supply
Voltage: AC100V-240V 50/60Hz
Power: 450W
Functional Effect
Color wheel: 14 color chips + white light, with a two-way
rotating rainbow effect
Gobo wheel: 17 gobos + white light, with gobo shake and
gobo arbitrary positioning function
Prism disc: 16+8 prisms/1 prism, prisms are optional
and can be rotated in both positive and negative
directions
Strobe: Double steel knife strobe frequency up to 13
times per second, and random strobe and pulse strobe
can be selected
Dimming: 0%-100% linear dimming
Atomization: 0%-100% linear atomization
Built-in macro function
The dimming range is 0-100% adjustable
Controls Program
Channel mode: international standard DMX512
channels, 16/18 channels
Master-slave self-propelled automatic synchronization
function.
The console normally controls self-propelled permanent
synchronization.
It can realize the function of remote pointing and
defoaming.
Equipped with DMX512 interface.
Built-in program self-propelled function.
Master-slave online mode.
Panel display: LCD liquid crystal display
Pan&Tilt Axis
Pan rotation angle: 540° (8/16 bits)
Tilt rotation angle: 270° (8/16 bits)
Pan&Tilt axis position correction
Lighting Specifications
Height: 520 mm
Width: 410mm
Depth: 330mm
Net weight: 16KG
Protection class: IP20
Working environment: 0-45℃
