Light Source
Light source: 371W lamp
Life expectancy: 2,200 hours
Optical System
Lens: high-precision optical lens
Dimmer: Smooth dimming from 0-100%
Color temperature: 3200K-8000K linear adjustment
Zoom: 2.5°-52°
Linear Dimmer: Mechanical Dimmer 0-100%
Power Supply
Power supply with electronic auto ranging
Input voltage range: power supply 100-250V, 50/60Hz
Power Consumption: 550W
Functional Effect
Color plate: 11 colors + white
Rotating gobo wheel: 7 gobos + white light
Fixed gobo wheel: 14 fixed gobos + white light
Strobe: double-lens strobe (0.5-9 times/second)
Prism: 8 circular rotating prisms + multi-faceted
prisms
Dimming: 0-100% linear dimming
Focus: linear adjustment
Frost Effect: atomizing mirror
Controls Program
Signal interface: optional three-core card base/fivepin
card base
Support protocol: DMX512
DMX mode (20/25 control channels)
LCD operation
Built-in demo sequence
DMX data in/out: Locking 3-pin and 5-pin XLR
AC power input: 1.5m power cord with plug
powerful three-phase motor
Pan&Tilt Axis
Pan rotation angle: 540° (8/16 bit precision scanning)
Tilt rotation angle: 270° (8/16 bit precision scanning)
Pan&Tilt axis position correction
Lighting Specifications
Height: 570 mm
Width: 438mm
Depth: 260mm
Net weight: 19KG
Gross weight: 21KG
Protection class: IP20
Working environment: 0-45℃
