Light source
Light Source: 280W Bulb
Life expectancy: 2,000 hours
Optical System
The advanced optical system ensures clear, sharp
image quality
A high-efficiency optical system, with a ratio of 1:6.4
Control & Program
4-touch buttons
Display: Color display
Protocols: DMX512
DMX modes: 2
Control channels: 16,24CH
PAN & TILT
Pan movement: 540°
Tilt movement: 270°
Pan/Tilt resolution: 16-bit
Automatic Pan/Tilt position correction
Rotating Gobos
1 x rotating gobo wheel with 12 gobos + open,
convenient replacement
Thickness: 1.1mm
Borofloat (or better) glass materials
Slot & Lock system for Gobo replacement
Static Gobos
1x static gobo wheel with 17 gobos + open
Color Wheel
1x color wheel with 14 colors + open
Electrical & Connectors
Power supply with electronic auto-ranging
Input voltage range: AC 100-240V, 50/60Hz
Power consumption: 420W
Power connector input
Data in/out: 3-pin
Electronic ballast
Lighting Specification
Height: 570 mm
Width: 450 mm
Depth: 430 mm
Weight: 20 kg
Protection class: Ip20
Working environment: 0-45℃
