Light Source
Light source: 19x15W RGBW LED
LED life expectancy: 20,000 hours
Optical System
The advanced optical system ensures a clear
and wide-ranging beam & washing effect
High-efficiency zoom optical system, ratio1:6
Beam Angle: 4° – 60°
Controls Program
Display: LCD display
Protocol: DMX512
Control channel: built-in 6-channel modes 23CH
(normal)/21CH (standard)/35CH (image)/78CH
(extendable) /96CH (RGBW extensible) /92CH
(all)
Dimmer: 16 bits
Dimming: 0-100% linear dimming
Strobe: 1-20 times/second with various
strobe effects
Pan/Tilt Axis
Pan axis movement: 540° 16-bi
Tilt axis movement: 250° 16-bi
Automatic pan/tilt position correction
Electrical Control
Power supply with electronic auto-ranging
Input voltage range: AC 100-240 V, 50/60 Hz
Power Consumption: 450W
Lighting Specifications
Height: 425 mm
Width: 415mm
Depth: 275mm
Net Weight: 14.95 kg
Gross weight: 18.1 kg
If you are looking for a stage lighting solution, we will provide you with a one-stop solution.
