Light Source
Light source: 37x15W RGBA LED
LED life expectancy: 20,000 hours
Optical System
The advanced optical system ensures a clear and
wide-ranging beam&washing effect
High-efficiency zoom optical system, ratio 1:6
Zoom range: 3° – 50°
Controls Program
Display: LCD display
Protocol: DMX512
DMX protocol mode: 4
Control channel: 24CH/48CH
Dimmer: 16 bits
Pan/Tilt Axis
Pan axis movement: 540°
Tilt axis movement: 190°
Pan/Tilt Resolution: 16-bit
Automatic pan/tilt position correction
Electrical and Connectors
Power supply with electronic auto-ranging
Input voltage range: AC 100-240 V, 50/60 Hz
Power Consumption: 500W
Power connector input
Data In/Out: 3-pin XLR
Lighting Specifications
Height: 560 mm
Width: 490mm
Depth: 440mm
Net weight: 12.7 kg
Gross weight: 15 kg
working environment
Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C
If you are looking for a stage lighting solution, we will provide you with a one-stop solution.
