Light Source
Light Source: 260W
Life expectancy: 2,000 hours
Optical System
The advanced optical system ensures clear,
sharp image quality
High-efficiency optical system
Beam angle: 2°
Control & Program
4-button touch panel
Display: Color display
Protocols: DMX512,Master/Slave
Control channels: 16CH, 20CH
Electronic ballast
PAN & TILT
Pan movement: 540°
Tilt movement: 270°
Pan/Tilt resolution: 16-bit
Automatic Pan/Tilt position correction
Static Gobos
1x static gobo wheel with 16 gobos plus open
Color Wheel
1x color wheel with 14 colors plus white
Electrical & Connectors
Power supply with electronic auto-ranging
Input voltage range: AC 100-240V, 50/60Hz
Power consumption: 320W
Data in/out: 3-pin XLR
Lighting Specification
Height: 565 mm
Width: 350 mm
Depth: 253 mm
Weight: 17kg
