Light Source
Light source: 371W/350W
Average lifespan: 2,000H (bulbs and reflectors are
packaged as a whole with higher light efficiency and longer
service life)
Optical System
Lumen value: 109 800 lux@ 20 meters
Color temperature: 8500K
Beam Angle: Parallel Beam Angle: 0-3.8°
Smart bulb switch control (extends bulb life)
Power Supply
Power supply: AC100V-240V 50-60Hz
Power: 500W
Fuses: 5A
Functional Effect
Dimming: 0-100% linear adjustment; overheating
intelligent protection
Strobe: double-chip strobe (0.5-9 times/second),
complete linear dimming, and variable strobe speed
Color wheel: with 14 colors + blank (can create sharp aerial
beam effect)
Gobo wheel: with 12 fixed gobos + blank (allows you to
quickly change the shape of the beam)
Prism: rotating 8-sided prism and 16-sided prism
Colorful effect can be rotated in both directions and the
speed of rotation can be adjusted to make the pattern
projection effect more abundant
Atomization: Atomization enlarges the soft light effect,
easily achieves a soft and dreamy pattern effect, and the
proportion of atomization is enlarged
Anti-shooting high-temperature internal treatment design
structure
Focusing: Using 2 sets of optical lens combinations, the
effect is far better than the usual beam light and can
project high-definition patterns
Controls Program
Number of motors: a total of 13 silent motors
International standard control signal: DMX512
Number of channels: 19CH
Pan&Tilt Axis
Pan rotation angle: 540° (8/16 bits)
Tilt rotation angle: 270° (8/16 bits)
Pan&Tilt axis position correction
Lighting Specifications
Height: 580 mm
Width: 320 mm
Depth: 220mm
Net weight: 20.35KG
Protection class: Ip20
Working environment: 0-45℃
