Working voltage: AC110V 〜 240V
Frequency: 50 / 60Hz
Features:
DMX512 standard. 512 DMX control channels.
2 photoelectric isolation independent output drive ports,
with resistance to 1500VDC electrical shock. Independent
board structure, easy to replace.
Can control 32 sets of 16-channel scanners
Large LCD display with backlight for displaying various
operating parameters.
16 channel faders, 1 speed control fader.
Storage capacity of 1600 chases. 48 chase programs, each
program has a maximum of 100 steps. Each step’s speed
and gradient parameters are set independently. Optional
music synchronization or manual speed control.
With the cooperation of the chase rate fader, the time range
of the program step can be from 0.03s-180s
48 scanner scenes that can be called directly.
It can run 4 chase programs and 48 scenes at the same time,
and can simultaneously run 32 lanterns manually (lifting
lights). The manual operation (lifting lights) has the channel
release function.
The X / Y of different kinds of scanners are controlled by the
data wheel, and can also be controlled by the faders.
16Bit computer light X / Y control accuracy.
15 environment keys to quickly call different scenes, chases,
and manual operation combinations.
The music trigger signal source can be taken from the audio
line input or the built-in microphone pickup.
It is easy to learn and use, and the operation efficiency is
higher.
Shutdown data remains.
Built-in high-performance green switching power supply,
with extremely low power supply harmonic distortion and
extremely wide voltage application range, in line with world
power requirements (90V-240V).
Size: 56.5 × 40 × 17.5cm
Gross weight: 8kg
