Light Source
250W High Output White LED
50,000 hours lifespan and low power consumption
Optical System
Zoom angle 5.5°~30°, focus function
High light output,13300LUX@5M at White light
zoom-in, 950LUX@5M at White light zoom out
Controls And Procedures
Color Wheel: 7 colors +white, color fine-tuning,
rotation with variable direction and speed
1 Rotation Gobo Wheel: 7 gobos + white, wheel
rotation and shake
1 Static Gobo Wheel: 8 gobos + white, wheel
rotation and shake
Prism: 8-facet Prism, bi-directional rotatable at
variable speeds
Frost Effect
High-speed strobe effect with 1-25 flashes per
second
Control Program
Control Signal: DMX 512, master-slave and sound
activated or auto operation
Control Channel: 16/18 DMX Channels USITT
DMX-512
Colorful LCD display
Pan And Tilt
Pan scan: 540° (16-bit precision scan)
Tilt scan: 270° (16-bit precision scan)
Automatic pan/tilt position correction
Electrical And Connectors
Input Voltage: AC90-260V 50/60Hz
Power Consumption: 350W
3-pin & 5-pin XLR connectors IN/OUT
Lighting Specifications
Length: 320 mm
Width: 220mm
Height: 480 mm
Product net weight: 13.50kg
Packing size: 365(L)*280(W)*600(H)mm
Product gross weight: 16.50kg
Protection level: Ip20
