Light Source
Total Laser Power: 4W RGB laser
Laser Power/Wavelength: 8pcs 500mW 638nm red
Laser Safety: Class 3B
LED:7*3W Amber LED (beam angle 7°)
Optical System
Effect: 0-100% smooth linear dimming, no jitter; refresh frequency
20500Hz.
Illumination transition is balanced, with no speckle, no visible relative
dark area
Remarks: Other RG, GB, RB, and RGB color versions are available too!
Control Program
Modulation: TTL
Control Mode: DMX/Auto/Sound/Master-slave
DMX Channel: 7/16CH
Display: LED display with 4 buttons
Scan System: stepping motor
Function Effect
1. 8pcs fat beam laser diodes
2. Single laser diode control
3. 7pcs 3W amber LED with beam angle 7°
4. projects strong and sweeping fat beam with 180° TILT, and makes a
great and cost-effective beam show,
5. Applicable for disco, club, KTV, pub, Bar, family party etc.
Tilt Axis
Tilt: 180°
Electrical Control
Power Consumption: 68W
Input Voltage: AC 100-240V 50/60Hz
Lighting Specification
Height: 173mm
Width: 84mm
Length: 1000mm
IP Rating: IP20
Weight: 12kG
N.W.(KG): 6.8KG
G.W.(KG): 7.3KG
Carton Size: 122*36*25cm (2pcs/carton)
