Light Source
Total Laser Power:3W red laser
Laser Power/Wavelength:6pcs 500mW 638nm red
Laser Safety: Class 3B
Optical System
Features:semi-conduct laser diode with long lifespan and stable
performance
laser beam size: 3.5cm at 3m distance, single laser control
Control Program
Control Mode: DMX/Auto/Sound/Master-slave
DMX Channel:9/19-1/19-2CH
Display: LED display with 4 buttons
Function Effect
1. 6pcs fat beam laser diodes
2. Single laser diode control
3. semi-conduct laser diode with stable performance and long
lifespan
4. Sweeping fat beam with Tilt of 90° and Pan 240° to make a
great and cost-effective beam show,
5. applicable for disco, club, KTV, pub, Bar, etc.
Pan/Tilt Axis
Pan:240°
Tilt:90°
Electrical Control
Power Consumption:90W
Input Voltage: AC 100-240V 50/60Hz
3pin DMX input/output, Power Con input/output，
Lighting Specification
Height: 129mm
Width: 230mm
Length: 1000mm
IP Rating: IP20
N.W.(KG):12.9KG
G.W.(KG):15.1KG
Carton Size:124*46*33cm(2pcs/carton, G.W:34.2KG)
