HL-PLB06A 6PCS 6in1 LED Wireless Battery Par Light

6PCS 6in1 LED Wireless Battery Par Light using 6pcs 18W RGBWU-V6in1 LED, combines powerful output, shiny beam, and colorful wash into its solid body. In order to meet the professional’s requirement, we designed Coolie1 6 pcs 18W as a versatile soldier, featuring 0~100% smooth dimming with 4 variable dimming curves, an outstanding strobe effect with variable speed, variable preset macro effects, and smooth color mixing&changing, to create the psychedelic effect. With robust construction and IP66-ratings, the Coolie 545 is designed for both indoor and outdoor use. Its durable aluminum die-casting housing protects it from dust, sand, moisture, and liquids, making it ideal for use in all situations from dusty deserts to rainy fields, from stage lighting to outdoor architectural use. For better protection and transportation, flight cases are your option.



Features

  • Light source: 6 x 18W RGBW U-V LED
  • Beam Angle: 15/25/30 degree°
  • With powerful beam and wash effects
  • Excellent color mixing effect
  • Preset program in stand-alone mode
  • 4 dimming curves
  • 0~100% smooth dimming
  • Outstanding strobe effect with variable speed
  • Dust-proof and oil-proof design
  • Flicker-free management
  • CH Mode:10CH/6CH

Technical Specification

Light source

  • Light source: 6 x 18W RGBW U V LED
  • LED life expectancy: 20000 hours



Optical system

  • The advanced optical system to ensure clear and large-range beam & wash effect
  • Beam Angle: 15/25/30 degree°



Control and Program

  • 4-buttons
  • Display: LED display
  • Protocols: DMX, Master/Slav
  • DMX Protocol modes: 3
  • Control channels: 6,10CH



Electrical and Connectors

  • Power supply with electronic auto-ranging
  • Input voltage range: AC 100-240 V, 50/60 Hz
  • Power consumption: 90 W
  • Power cord out
  • Data in/out: 3-pin XLR socket
  • Fuse standard is 2A/250V



Fixture Specification

  • Height:215 mm
  • Width: 180mm
  • Depth: 215 mm
  • Weight: 3.5 kg



Work Environment

  • Maximum surface temperature: 35°C
  • Minimum operating temperature: 0°C



Installation

  • Horizontally or vertically mounting are available
  • The operating position is universal
  • The feet support with 3 locking points
  • Safety cable attachment point



Included Items

  • User Manual
  • Power Cable
  • The feet support with 3 locking points



Optional Accessories (with item code)

  • Flight Case
  • Clamps:
  • Signal Line:3-pin signal line
  • Safety cable :

Effect Demonstration

hl plb06 6pcs 6in1 wireless dmx battery waterproof par light (1)

Product Video

Inspiration

hl plb06 6pcs 6in1 wireless dmx battery waterproof par light (1) application 0010 bar

Dimensions

Downloads

DMX Channel

Product Data

Software Updates
