Light Source
Light source: 480W
Life expectancy: 2,000 hours
Optical System
Luminous flux: 29000LM
Light output angle: 1.9°
Color temperature: 7000K
Lens diameter: 180MM
Lens: high-precision optical lens
Power Supply
Input voltage: AC115/230V 50/60Hz
Input power: 650W
Functional Effect
Color wheel: 13 colors + white light, two-way
variable speed rainbow effect
Gobo wheel: 17 fixed gobos + white light
Atomization: 1 atomizing mirror
Double prism: 8-16 prism bidirectional variable
speed rotation
Dimming: 0-100% linear adjustment
Strobe: 1-13 times/second
Focus: electronic focus
Controls and Procedures
Control mode: DMX/DRM/DMX antenna
(optional)
Channel mode: 19 channels in simplified mode,
24 channels in standard mode
Display system: LED touch screen can be
rotated 180 degrees
Pan&Tilt Axis
Pan rotation angle: 540° (8/16 bits)
Tilt rotation angle: 270° (8/16 bits)
Pan&Tilt axis position correction
Lighting Specifications
Height: 640mm
Width: 400 mm
Depth: 285mm
Net weight: 21.5KG
Protection class: IP20
Working environment: 0-45℃
